3 Ton Trane Choice 14 Packaged Heat Pump
Pick a size
AHRI certificate 216574920: 13.4 SEER2, 11 EER2, 6.7 HSPF2
Packaged unit 5WCC4024A1000
Trane packaged heat pump, 2 ton nominal, 208-230V single phase, R-454B, convertible downflow or horizontal
Warranty: Trane’s manufacturer warranty. The exact terms for this model are confirmed at your estimate. You register it, and my post-install email sends you the link.
Auxiliary electric heat BAYHTRG108A
6.0/8.0 kW (208/240V) supplementary electric heater
Warranty: 10-year limited parts warranty on the electric heater. Parts only, not labor.
Thermostat TCONT302AS42DA
Trane programmable thermostat
Warranty: 5-year parts warranty on the thermostat when registered. Parts only, not labor.
AHRI certificate 216574922: 13.4 SEER2, 11 EER2, 6.7 HSPF2
Packaged unit 5WCC4030A1000
Trane packaged heat pump, 2.5 ton nominal, 208-230V single phase, R-454B, convertible downflow or horizontal
Warranty: Trane’s manufacturer warranty. The exact terms for this model are confirmed at your estimate. You register it, and my post-install email sends you the link.
Auxiliary electric heat BAYHTRG108A
6.0/8.0 kW (208/240V) supplementary electric heater
Warranty: 10-year limited parts warranty on the electric heater. Parts only, not labor.
Thermostat TCONT302AS42DA
Trane programmable thermostat
Warranty: 5-year parts warranty on the thermostat when registered. Parts only, not labor.
AHRI certificate 216574924: 13.6 SEER2, 11 EER2, 6.7 HSPF2
Packaged unit 5WCC4036A1000
Trane packaged heat pump, 3 ton nominal, 208-230V single phase, R-454B, convertible downflow or horizontal
Warranty: Trane’s manufacturer warranty. The exact terms for this model are confirmed at your estimate. You register it, and my post-install email sends you the link.
Auxiliary electric heat BAYHTRG110A
7.5/10.0 kW (208/240V) supplementary electric heater
Warranty: 10-year limited parts warranty on the electric heater. Parts only, not labor.
Thermostat TCONT302AS42DA
Trane programmable thermostat
Warranty: 5-year parts warranty on the thermostat when registered. Parts only, not labor.
AHRI certificate 216574926: 13.6 SEER2, 11 EER2, 6.7 HSPF2
Packaged unit 5WCC4042A1000
Trane packaged heat pump, 3.5 ton nominal, 208-230V single phase, R-454B, convertible downflow or horizontal
Warranty: Trane’s manufacturer warranty. The exact terms for this model are confirmed at your estimate. You register it, and my post-install email sends you the link.
Auxiliary electric heat BAYHTRG110A
7.5/10.0 kW (208/240V) supplementary electric heater
Warranty: 10-year limited parts warranty on the electric heater. Parts only, not labor.
Thermostat TCONT302AS42DA
Trane programmable thermostat
Warranty: 5-year parts warranty on the thermostat when registered. Parts only, not labor.
AHRI certificate 216574928: 13.4 SEER2, 11 EER2, 6.7 HSPF2
Packaged unit 5WCC4048A1000
Trane packaged heat pump, 4 ton nominal, 208-230V single phase, R-454B, convertible downflow or horizontal
Warranty: Trane’s manufacturer warranty. The exact terms for this model are confirmed at your estimate. You register it, and my post-install email sends you the link.
Auxiliary electric heat BAYHTRG115A
11.27/15.0 kW (208/240V, two element) supplementary electric heater
Warranty: 10-year limited parts warranty on the electric heater. Parts only, not labor.
Thermostat TCONT302AS42DA
Trane programmable thermostat
Warranty: 5-year parts warranty on the thermostat when registered. Parts only, not labor.
AHRI certificate 216574930: 13.6 SEER2, 11 EER2, 7 HSPF2
Packaged unit 5WCC4060A1000
Trane packaged heat pump, 5 ton nominal, 208-230V single phase, R-454B, convertible downflow or horizontal
Warranty: Trane’s manufacturer warranty. The exact terms for this model are confirmed at your estimate. You register it, and my post-install email sends you the link.
Auxiliary electric heat BAYHTRG115A
11.27/15.0 kW (208/240V, two element) supplementary electric heater
Warranty: 10-year limited parts warranty on the electric heater. Parts only, not labor.
Thermostat TCONT302AS42DA
Trane programmable thermostat
Warranty: 5-year parts warranty on the thermostat when registered. Parts only, not labor.
Pay cash or check and it’s about 10% off. Pick it under “How do you plan to pay?”
A packaged heat pump + electric backup heat in one cabinet that sits outside on a pad and connects to your existing ductwork. The power entry kit, plenum or transition and pad are confirmed at the estimate visit.
Not sure of your size? The old nameplate is a starting point, not the answer. I run a load calculation at the estimate visit.
Add to your system
Most installs need nothing extra. About 1 in 10 homes needs new ductwork, and I’ll tell you at the estimate visit.
Most homes need I check these at the estimate visit and reuse what’s good.
Nice to have Optional upgrades.
Without my professional installation there is no warranty from me, and a manufacturer can deny its warranty when the equipment is not installed by a licensed HVAC contractor.
Federal EPA Section 608 rules require an EPA certified technician to handle the refrigerant in this equipment. To buy equipment only, I need a copy of your EPA 608 certification, or the certification of the technician installing it.
Your size and final price are confirmed in writing after the load calculation, before anything is ordered.
Equipment only is available if you’d rather. Refrigerant-charged equipment has to be installed by an EPA Section 608 certified technician, the warranty has to be registered on time and covers parts, not labor, and equipment is ordered for your job, so ask me about returns before you buy.
- Sizes
- 2, 2½, 3, 3½, 4, 5 ton
- Type
- Packaged heat pump + electric backup heat
- Stages
- Single-stage
- Setup
- Outside on a pad, connected to your existing ductwork
- Certified efficiency
- 13.4 to 13.6 SEER2 by size, 6.7 to 7 HSPF2 (AHRI certified sizes)
Efficiency is the AHRI-certified rating for each size, shown with its certificate number.
What these terms mean
- SEER2
- Cooling efficiency over a whole season. Higher means less power for the same cooling. The number shown is the AHRI-certified rating.
- EER2
- Cooling efficiency on a hot 95 degree afternoon, the kind of day Oklahoma has all July.
- HSPF2
- Heat pump heating efficiency over a winter. Higher is better.
- Single-stage
- Runs full speed or off. Simple and reliable.
- Two-stage
- Runs on low most of the time and high on the hottest days, for steadier temperatures.
- Dual fuel
- A heat pump does most of the heating, and the gas furnace takes over when it gets really cold.
- AHRI certificate
- An independent certificate that this exact outdoor unit, coil and furnace or air handler were tested together and earn the rating shown.
- R-454B and R-32
- The refrigerants in today’s new equipment. Manufacturers stopped building new R-410A systems at the start of 2025.
When the house is set up for a package unit, swapping like for like is the simplest, cleanest job there is.
Dave Hartzell, Master HVAC
Install day
- Before install day: an estimate visit, Manual J load calculation, and a check of the pad, duct connection, power and gas. Then your written quote.
- I protect walkways, shut off power and gas, and take out the old package unit.
- New unit set and leveled on the pad and connected to your existing ductwork, with a new transition where it needs one.
- Power, gas where it has gas heat, and condensate connected.
- Startup readings written down: pressures, temperatures and airflow.
- Cleanup, a walkthrough of the thermostat and filter, and the old unit hauled off.
Your install date comes with your written quote. See my full install standard.
Warranty
- Trane’s manufacturer warranty. The exact terms for this model are confirmed at your estimate. You register it, and my post-install email sends you the link.
- My 1-year labor warranty on the installation
Manufacturer warranties cover parts, not labor. My 1-year labor warranty covers the installation.
Paying for it
Ways to pay: cash or check (about 10% off every price), credit cards, and financing through Hearth, Wisetack, JB Financing, Klarna, Synchrony and Wells Fargo. Cash is king, and I take cards too. Hearth, Wisetack, Klarna and JB Financing check offers with a soft credit pull, so looking won’t touch your score. Hearth works with credit scores as low as 550. Subject to credit approval.
Questions about this package unit
How much does a Trane Choice 14 packaged heat pump cost in Kingfisher Oklahoma?
Pick your system size above: each size shows the package unit price, my $3,200 professional installation and the total. The smallest size starts at $14,090 for the equipment, and you see the final price in writing before anything is ordered.
Will a package unit fit my house?
A package unit sits outside on a pad and connects to your existing ductwork. At the estimate visit I check the duct connection, the pad, power, and the power entry kit, transition and pad are confirmed then.
How do I know what size I need?
I run a Manual J load calculation on your house at the estimate visit, so the size comes from the math, not the old unit’s nameplate.
Can I buy the equipment only?
Equipment only is available if you’d rather. Refrigerant-charged equipment has to be installed by an EPA Section 608 certified technician, the warranty has to be registered on time and covers parts, not labor, and equipment is ordered for your job, so ask me about returns before you buy.
Can I finance it?
Ways to pay: cash or check (about 10% off every price), credit cards, and financing through Hearth, Wisetack, JB Financing, Klarna, Synchrony and Wells Fargo. Cash is king, and I take cards too. Hearth, Wisetack, Klarna and JB Financing check offers with a soft credit pull, so looking won’t touch your score. Hearth works with credit scores as low as 550. Subject to credit approval.
